GX12 3-Pin Metal Connector Cable

GX12 3-Pin Metal Connector Cable for Industrial Automation & Sensor Networks

Engineered for reliable signal and power transmission in harsh environments, our GX12 3-Pin Metal Connector Cable features a rugged nickel-plated brass shell, IP67-rated sealing, and 100% continuity testing—backed by 17 years of OEM manufacturing to ensure zero signal loss in factory automation and control systems.

Why Choose Our GX12 3-Pin Connector Cables?

In industrial automation, a loose or corroded connection can halt an entire production line. Our GX12 cables are designed to eliminate these risks with precision threading, gold-plated contacts, and robust strain relief—meeting the strict demands of sensor manufacturers and system integrators.

Superior Corrosion Resistance & Mechanical Strength

The nickel-plated brass shell provides exceptional protection against moisture, oil, and vibration, outperforming standard plastic connectors. The 3-pin configuration supports both power (up to 5A) and signal (shielded options available) in a compact footprint, making it ideal for proximity sensors, encoders, and solenoid valves.

Precision Contact & Stable Signal Integrity

Gold-plated brass pins (3µ" minimum) ensure low contact resistance (<10mΩ) and withstand 500+ mating cycles. Twisted-pair or shielded cable constructions are available to suppress EMI/RFI in high-noise environments like welding cells or motor drives—a critical factor often overlooked by generic cable suppliers.

Custom Lengths & Rapid Turnaround for System Upgrades

We maintain dedicated tooling for GX12 overmolding, enabling custom lengths from 0.5m to 20m with 15–20 working day lead times. Our in-house extrusion and assembly lines allow us to match your exact color, cable jacket (PUR/PVC), and pin-out configuration, reducing downtime during equipment retrofits.

Complete Product Specifications

Professional Applications You Can Trust

Automotive assembly lines use our GX12 cables for connecting inductive proximity sensors to PLC I/O modules—the metal housing withstands weld spatter and coolant splash, while the secure 3-pin interface prevents intermittent faults that trigger false machine stops.

Packaging machinery manufacturers integrate these cables into servo motor feedback loops and photoelectric sensors. The shielded version maintains encoder signal integrity over 10-meter runs, eliminating jitter that causes packaging misalignment.

Robotic cells and AGV (automated guided vehicle) systems rely on the GX12's compact diameter and flexible PUR jacket for continuous flexing applications, with 5 million bend cycle tested options available for dynamic cable tracks.

Advanced Safety Features

Each assembled cable undergoes 100% Hi-Pot testing (1,500VAC) to verify insulation integrity, followed by a continuity check on all three pins—any intermittent connection triggers automatic rejection. This ensures field reliability under thermal cycling and vibration.

The threaded coupling mechanism includes a vibration-proof locking nut that maintains a secure connection even in high-shock environments (up to 10g acceleration). A polarized keyway prevents mismating, protecting sensitive downstream electronics from reverse voltage damage.

For applications requiring ATEX or IECEx compliance, we offer an intrinsically safe version with current-limiting resistors and encapsulated potting, specifically designed for hazardous area sensor networks.

Manufacturing Excellence

With 17 years of experience in industrial connector cable assembly, we operate a 15,000m² ISO 9001:2015 and IATF 16949-certified facility. Our automated soldering stations and overmolding presses ensure consistent contact alignment and strain relief, with inline cameras inspecting each pin's solder joint quality. We conduct periodic salt spray, thermal shock, and tensile pull tests on every production lot, providing traceable test reports to support your quality management system.

Frequently Asked Questions

Can the GX12 cable be used for both power and signal in the same assembly?

Yes, the 3-pin configuration supports mixed applications. We recommend designating Pin 1 for common ground, Pin 2 for power (max 5A), and Pin 3 for signal. For higher power, we can customize with 18 AWG wires on the power pins.

Do you offer pre-wired GX12 connectors with flying leads or junction boxes?

Absolutely. We provide both molded cables with overmolded connectors and pre-stripped flying leads for panel mounting. For multi-point systems, we can assemble GX12 to terminal block pre-wired harnesses.

What is the lead time for custom color cables or non-standard pin-outs?

Custom color jackets (RAL or custom) require 15 working days for sample, 20–25 days for mass production. Non-standard pin assignments are simply handled during our soldering process with no extra tooling cost and 10-day sample delivery.

How do you validate the IP67 rating on assembled cables?

We randomly sample each batch for IPX7 submersion testing (1m depth for 30 minutes) and IP6X dust ingress testing. Test reports are included in our quality documentation package for your compliance records.

Custom Solutions for Your Business

Beyond standard GX12 3-pin, our engineering team can develop hybrid connectors (e.g., 4-pin with additional shield drain), overmolded Y-splitters, or right-angle variants for tight spaces. We also offer custom laser marking for part numbers and batch codes. Typical NRE for new housing designs is 5–7 days; production tooling takes 20–25 days. We manage the complete process from 3D modeling to UL/CE pre-approval, delivering fully qualified assemblies for your critical automation projects.

Contact Us

Ready to discuss your GX12 3-Pin Metal Connector Cable requirements? contact us at liz@szkuncan.net for expert guidance and competitive pricing.
